In Europe, the growth of electric vehicles (EVs) has led to an expansion of charging points, offering drivers a range of options to suit their needs. These charging points are categorized by their power delivery rates and plug types, and can be found in homes, public spaces, and highway service areas.
1. Slow/AC Charging (Up to 22 kW)
Slow chargers, delivering up to 22 kW AC power, are the most common type of charger found in homes and some public locations. They use AC power that is converted by the car’s onboard charger. The two most common plug types for slow chargers are Type 1 and Type 2.
Type 1 plugs are single-phase and can provide up to 7.4 kW, mainly for older or imported vehicles. Type 2 plugs, on the other hand, support three-phase power levels, with home chargers offering up to 22 kW and public chargers offering up to 43 kW.
2. Fast Charging (AC or lower-end DC, ~22-50 kW)
Fast chargers deliver power at a rate of 22-50 kW and can be found in public locations, workplaces, and some high-power public stations. These chargers can replenish 80% of a vehicle's range in about an hour.
3. DC Fast Charging / Ultra-fast Charging (50 kW to 350 kW)
DC fast chargers and ultra-fast chargers provide direct current (DC) power to the battery, bypassing the onboard charger, enabling very fast replenishment. These chargers can add up to 300 km range in 20-30 minutes or less.
The main plug types for DC fast charging are CCS2 (Combined Charging System Type 2) and CHAdeMO. CCS2 is the European preferred standard, supporting both AC and DC charging, and power up to 350 kW. CHAdeMO is a Japanese standard, maxing out at around 100 kW, and supports bidirectional charging but is less common in Europe.
Typical usage scenarios and access:
- Home charging: Mostly slower AC chargers (7.4 to 22 kW), convenient for overnight charging.
- Public charging: A mix of AC fast chargers and DC fast chargers, located in city centers, malls, workplaces, and especially along highways.
- Plug-in options: Type 2 is the most prevalent plug for AC charging across Europe; for fast DC charging, CCS2 dominates due to compatibility and power capabilities, while CHAdeMO is less common but still in use for some models.
Summary of key plug types and power levels:
| Charging Type | Power Delivery | Plug Types | Typical Locations | Charging Time Example | |--------------------|--------------------|---------------------|-------------------------------------------|----------------------------------------------| | Slow AC | Up to 7.4 kW | Type 1 (single-phase) | Home, some public | Overnight or several hours for full charge | | Fast AC | Up to 22-43 kW | Type 2 (three-phase) | Home, public, workplaces | Few hours | | DC Fast Charging | 50 kW - 350 kW | CCS2 (Europe), CHAdeMO | Highway service stations, dedicated fast stations | ~20-30 minutes to 80% charge (up to 300 km range) |
This tiered infrastructure supports diverse EV charging needs from daily home use to high-speed recharges on long trips.
As of the first quarter of 2024, there were 818,819 public charging points available across Europe. Eastern European countries have a higher total power output in charging points, demonstrating the effectiveness of focusing on high-power charging points. Countries like the Netherlands, Germany, France, the United Kingdom, and Belgium make up 66% of Europe’s EV infrastructure.
The Netherlands had the highest number of publicly available charging points with 154,219 locations, followed by Germany with 130,828 charging points, and France placed third with 127,530 locations. This widespread charging network showcases the importance of a robust charging infrastructure to support a larger EV fleet, especially in Western European countries.
Examples of charging networks include IONITY, which provides up to 350 kW chargers at European highways and service stations, and Fastned, which operates ultra-rapid stations across parts of the UK and Europe, offering around £0.48-£0.69 per kWh pricing depending on membership.
In conclusion, the growth of EV charging points across Europe offers drivers a wide range of options to suit their needs, from slow AC chargers for home use to ultra-fast DC chargers for long trips. With a focus on high-power charging points and the expansion of charging networks, Europe is well-positioned to support the growing number of electric vehicles on its roads.
[1] IONITY (2022). About IONITY. Retrieved from https://www.ionity.co.uk/about-us/ [2] Fastned (2022). Charging stations in the UK. Retrieved from https://www.fastned.co.uk/en/map [3] Enphase Energy (2022). IQ EV Charger 2. Retrieved from https://www.enphase.com/products/solar-plus-storage/charging-stations/iq-ev-charger-2 [4] Green Car Reports (2021). Enphase IQ EV Charger 2 offers smart features, dynamic load balancing. Retrieved from https://www.greencarreports.com/news/1136259_enphase-iq-ev-charger-2-offers-smart-features-dynamic-load-balancing [5] Chargemap (2022). Charging station costs in Europe. Retrieved from https://www.chargemap.com/en/blog/2021/10/charging-station-costs-in-europe/
1. Environmental-science research has shown that the expansion of charging points for electric vehicles (EVs) not only supports sustainable living but also offers opportunities for data and cloud computing, as these points collect valuable data on energy usage and charging patterns.
2. The renewable-energy industry is collaborating with environmental-science researchers to develop more energy-efficient charging technologies, ensuring that the increased demand for electricity does not negatively impact the environment.
3. Finance institutions are investing heavily in the growth of EV infrastructure, recognizing it as a key driver for economic growth and job creation in the technology sector.
4. Energy-saving in one's home-and-garden can be enhanced by utilizing smart home devices, such as the Enphase IQ EV Charger 2, which offers dynamic load balancing and smart features that help manage energy consumption.
5. Lifestyle choices play a crucial role in reducing carbon emissions, and consumers are increasingly opting for EVs as a more environmentally friendly alternative to conventional vehicles.
6. Technology advancements in EV battery technology are making it possible for vehicles to travel greater distances using renewable energy sources, minimizing the need for fossil fuel-based energy and contributing to climate-change mitigation efforts.
